HPY Multi-Cylinder Hydraulic Cone Crusher show Its Charm at bauma China 2018

author:dahua time:2018-11-22

bauma China 2018 will be hold from December 27-30, 2018, at Shanghai. HPY multi-cylinder hydraulic cone crusher will be the fourth time on the exhibition. This cone crusher is one kind of high-class product combined with mechanical technology, electrical technology, hydraulic technology and advanced crushing technology, which can be widely used in secondary and fine crushing work for all kinds of hard materials and rocks to meet customers' various needs for crushing. Now, let me show you the real charisma of HPY multi-cylinder hydraulic cone crusher:

The machine adopts high strength casting-steel frame, alloy forging main shaft and high precision straight bevel gear driving structure, combined with multi-chambers selection and automation control system, which fulfills the performance and advantages.

        hpy cone crusher

Working principle:

When the hydraulic cone crusher works, electric motor drive the belt pulley or the gear shaft to rotate, drive shaft and cone body make the eccentric shaft periodically oscillating and rotating around the center axis. After the material enter into the crushing chamber, they are continuously striking, grinding and squeezing under the interaction of eccentric shaft and concave until the material reach the required granularity, and then discharged from the lower outlet.

hpy cone crusher working principle

Crushing Cavity Selection


1. Equipped with two impact crushing cavities which can be adjusted.

2. The upper and lower frame of crusher can all be dismounted, transported and installed in ease.

3. The two sides of it are mounted with unique openings which can be used to change the hammer and impact rack.

4. The machine self is cube-shaped and the discharge size of materials can be preset.

5. Easy operation and maintenance and high efficiency.

Luoyang Dahua has more than 30 years rich experiences in designing, manufacturing and installation of mining crushing machine. Welcome you visit our booth: E6-550.
